Mill Edge Stainless Steel Coil Strip Grades Finishes 1524 Mm

    Buy cheap Mill Edge Stainless Steel Coil Strip Grades Finishes 1524 Mm from wholesalers

    Buy cheap Mill Edge Stainless Steel Coil Strip Grades Finishes 1524 Mm from wholesalers
    • Buy cheap Mill Edge Stainless Steel Coil Strip Grades Finishes 1524 Mm from wholesalers

    Mill Edge Stainless Steel Coil Strip Grades Finishes 1524 Mm

    Ask Lasest Price
    Brand Name : Stainless Steel
    Model Number : 300 Series,400 Series
    Certification : ISO, AISI, ASTM, GB, EN, DIN, JIS
    Price : Contact Us
    Payment Terms : T/T L/C and Western Union etc.
    Supply Ability : 10000 Ton/Tons per Month
    Delivery Time : Within 7-10 Working Days
    • Product Details
    • Company Profile

    Mill Edge Stainless Steel Coil Strip Grades Finishes 1524 Mm

    The austenitic grades, also known as the chromium nickel types, are usually non- magnet, an easy task to weld and form, and gives excellent resistance from corrosion and good creep amount of resistance. Austenitic grades are nonhardenable by heat treating. Cold working raises potency and efficacy. Typically the most popular austenitic grades are type 304 and type 316L. All of us carry stocks in 304, 304L and 316L for quick transport as well as have an international network of suppliers if your production schedule and quantities permit a longer lead time. Surface finish for stainless metal sheet( coil, strip) and dishes, are specified in EN 10088- 2 SYM 2005. 'Metal steel- Technical delivery conditions for sheet/ plate and strip of corrosion resisting steels for basic purposes. 'The conventional recognizes both 'ex- work' hot and cold folded finishes and 'special finishes', as useful finishes to attain specific aesthetic effects. When stainless steel was performed and offered in products, the time came to hear another process: stainless metal polishing. Stainless- polishing improves the overall surface finish of any metal product. This raises the sanitary advantages of the items aswell. Metal steel strips would be the expansion products of ultra- slim metal plates, usually long and narrow metal pieces are created to match the needs of varied and mechanical areas.

    Product Specification and Steel Grade

    ASTMAISIEN
    Grade

    S30100

    S30400

    S30403

    S31008

    S31603

    S32100

    S41008

    S43000

    S43932

    S44400

    S44500

    301

    304

    304L

    310S

    316L

    321

    410S

    430

    -

    444

    -

    1.4310

    1.4301

    1.4307

    1.4845

    1.4404

    1.4541

    -

    1.4016

    1.4510

    1.4521

    -

    Available Size

    WidthThicknessInner DiameterAvailable Steel GradeSurface Finish
    610~1524 mm0.3~3.0 mm610 or 508 +0/-5 mm201, 202, 204 Cu3, 301, 304, 304L, 310S, 316L, 321, 409L, 410S, 420J2, 430, 439, 441, 444, 4452B, 2D, BA, No.3, No.4, No.5, SB, HL

    Dimension and Shape Tolerance (For Reference)

    Thickness (mm)630 ≤ Width < 1000 (mm)1000 ≤ Width < 1250 (mm)1250 ≤ Width < 1550 (mm)
    0.25 ≤ T < 0.40±0.030±0.035-
    0.40 ≤ T < 0.60±0.035±0.035-
    0.60 ≤ T < 0.80±0.040±0.040-
    0.80 ≤ T < 1.00±0.040±0.050±0.050
    1.00 ≤ T < 1.25±0.050±0.055±0.060
    1.25 ≤ T < 1.60±0.055±0.060±0.060
    1.60 ≤ T < 2.00±0.065±0.070±0.080

    Width Tolerance
    Mill EdgeCut Edge
    Aim ±10Aim -0 / +1

    Surface FinishMill EdgeCut Edge
    2B / BA10 mm5 mm
    2D20 mm10 mm

    Chemical Composition & Mechanical Property :

    Chemical Composition (For Reference)

    ASTM Specification

    Steel GradeNi% Max.Cr% Max.C% Max.Si% Max.Mn% Max.P% Max.S% Max.Mo% Max.Ti% Max.Other
    S301006.0~8.016.0~18.00.15120.0450.03--N: 0.1 Max.
    S304008.0~10.517.5~19.50.070.7520.0450.03--N: 0.1 Max.
    S304038.0~12.017.5~19.50.030.7520.0450.03--N: 0.1 Max.
    S3100819.0~22.024.0~26.00.081.520.0450.03---
    S3160310.0~14.016.0~18.00.030.7520.0450.032.0~3.0-N: 0.1 Max.
    S321009.0~12.017.0~19.00.080.7520.0450.03-5(C+N)~0.7N: 0.1 Max.
    S410000.7511.5~13.50.08~0.15110.040.03---
    S430000.7516.0~18.00.12110.040.03---
    S439320.517.0~19.00.03110.040.03--N:0.03Max.Al:0.15Max.Nb+Ti = [ 0.20 + 4 ( C + N ) ] ~ 0.75

    Mechanical Property (For Reference)

    ASTM Specification


    Steel GradeN/mm 2 MIN.Tensile StressN/mm 2 MIN.Proof Stress% MIN.ElongationHRB MAX.HardnessHBW MAX.HardnessBendability:Bending AngleBendability:Inside Radius
    S301005152054095217No Require-
    S304005152054092201No Require-
    S304034851704092201No Require-
    S310085152054095217No Require-
    S316034851704095217No Require-
    S321005152054095217No Require-
    S410004502052096217180°-
    S4300045020522A89183180°-
    S439324152052289183180°-
